Wire Mesh Fencing Manufacturer
5 Years
| Ask Lasest Price | |
| Brand Name : | LNF-Chain link Wire |
| Model Number : | 2.75" mesh |
| Certification : | ASTM392 ASTM396 |
| Price : | 8.88$ per liner meter |
| Payment Terms : | TT30% deposit balance 70% at sight of finished products |
| Supply Ability : | 10000 liner meters |
| Delivery Time : | 7 work days |
LN FENCING co manufactured chain link fence fabric is made quality commercial grade cold drawing medium carbon steel wire to moderate diameter coated available weaving before or after galvanized Chain link fabric made in LEADING NEW FENCING to conform to ASTM392 general zinc standard 366gram/SQM and 610 Gram/SQM also due to technology developed budget as client specified required recent then 10 years wire mesh fabric also available 100gram/QM 200gram/SQM as well 275gram/SQM and so on
Chain Link Fence Fabric Spec | |
MIN Mesh aperture | 3/8” equal to 9.52mm Highest security such as prison mesh |
MIN Mesh aperture | 2⅜” equal to 60.3mmIndustrial/Commercial such as residential |
Selvage | Knuckled twisted |
Noted | Installation guide please review ASTM 567 |
Dia Allowable Variance | ±0.13mm/±0.005” |
General Diameter | |
Sample 1 | 6GA /0.192”/4.88mm with minimum break strength 9650 newtons |
Sample 2 | 9GA /0.148”/3.760mm with minimum break strength 5740 newtons |
Sample 3 | 11GA/0.120” /3.05mm with a minimum break strength 3780 newtons |
LEADING FENCING cochain link fence fabric Height range from and available any height between 36” to 144” and a Roll size such as 50ft 100ft or specified according to your local realities. Galvanized Chainlink Fence Fabric with a wide application in Industrial Commercial and industry LN FENCING according to the United States ASTM396 and marketing and installation experience to give follow recommend usage.
l Prison
l road, dock, airport
l housing, forestry
l military use.
l And so on
Mesh aperture/mm/inch | Diameter available | Recommend Applications | |
50.8mmx50.8mm | 2”x2” | 6GA/4.88mm 9GA/3.66mm 11GA/2.95mm | Industrial/Commercial |
25.4mmx25.4mm | 1”x1” | 6GA/4.88mm 9GA/3.66mm | Industrial/Security |
High security for residential and Commerical etc | |||
25.4mmx25.4mm | 1”x1” | 9GA/3.66mm 11GA/2.95mm | |
19.0mmx19.0mm | 3/4”x3/4” | 9GA/3.66mm 11GA/2.95mm | |
15.8mmx15.8mm | 5/8”x5/8” | 9GA/3.66mm 11GA/2.95mm | |
12.7mmx12.7mm | 1/2”x1/2” | 9GA/3.66mm 11GA/2.95mm | |
9.50mmx9.50mm | 3/8”x3/8” | 11GA/2.95mm | |
Zinc Coated Chain Link Fabric For Tenis Court | |||
44.5mmx44.5mm | 13/4”x1 3/4” | 9GA/3.66mm 11GA/2.95mm | |
NOTED | |||
Specified spec chain link fence fabric is available we could according to your local reality to design and manufacturer suitability chain link fence in ideal GA diameter and mesh aperture as well height between an interval of 36’/914mm to 144”/ 3657.6mm | |||
Chain wire Diameter | Chain Mesh Aperture | Height of Zinc-Coated Chain Link Fabric /inch |
0.192”/6Ga/4.88mm | 2”x2”/ 50.8mmx50.8mm | 36, 42, 48, 60, 72, 84, 96, 108, 120, 144 |
0.148”/9Ga/3.66mm | 2”x2”/50.8mmx50.8mm 1”x1”/25.4mmx25.4mm | |
0.12”/11ga/2.95mm | 2”x2”/ 50.8mmx50.8mm | 36, 42, 48, 60, 72, 84 |
1.75”x1.75”/44.5mmx44.5mm | 96, 108, 120, 144 | |
1”x1”/25.4mm x 25.4mm | 36, 42, 48, 60, 72, 84, 96, 108, 120, 144 | |
0.113”/11.5/2.80mm | 21⁄8”x21/8”/54mmx54mm | 36, 42, 48, 60, 72 |
Noted | 1ft =12” | |
|
|
