Wire Mesh Fencing Manufacturer
5 Years
| Ask Lasest Price | |
| Brand Name : | LNF-Garrison Hercules Diplomate |
| Model Number : | 1800mm 2100mm 2400mm height |
| Certification : | ISO |
| Price : | 11.88% per liner meter |
| Payment Terms : | TT30% deposit balance 70% at sight of finished products |
| Supply Ability : | 10000 liner meters |
| Delivery Time : | 7 work days |
Material: | Steel |
|---|---|
Applications: | Schools, Business, Railways |
Quality: | Quality Endorsed |
Finishes: | Galvanised Steel |
Design options: | Through Rail |
Accessories and fittings: | Flanges - standard fixing to posts by 40mm x 40mm steel rail flanges and tek screws or anti-theft screws. They are anti-tamper and provide you with peace of mind. They can be supplied on request. All gates come complete with drop bolts, lugs, chain, striker and ball bearing hinges. |
Sliding Gates can be priced on application. Double Gates are
available in opening sizes up to 8000mm on request.
Standard Sizes
PANEL HEIGHTS (MM) | 1800, 2100 or 2400 |
|---|---|
PANEL WIDTHS (MM) | 2000 or 2400 |
HORIZONTAL RAILS (MM) | 40 x 40 x 1.6 |
VERTICAL PICKETS (MM) | 25 x 25 x 1.2 |
TUBE SPACING | 140mm Centres |
Posts
INGROUND POST HEIGHT (MM) | From 2700 - 3600 |
|---|---|
STANDARD POSTS SPECS (MM) | 65 x 65 x 2.0 |
Colours
BlackBlack
*These colours are samples only
|
|
