    Stainless Steel Cable Mesh For Architectural Construction Building Facade Safety

    Ask Lasest Price
    Brand Name : BMP -Stainless Wire Rope Mesh
    Model Number : ZOO WIRE MESH
    Certification : ISO
    Price : 9.88$/m2
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 20000sqm per week
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    Stainless Steel Cable Mesh For Architectural Construction Building Facade Safety

    Stainless Steel Cable Mesh For Architectural Construction Building Facade Safety
    Hole Size
    (Opening)
    1.2MM(3/64)
    (7 x 7 )
    1.6MM(1/16)
    (7 x 7 )
    2.0MM(5/64)
    (7 x 7 )
    2.4MM(3/32)
    (7 x 7 )
    3.2MM(1/8)
    (7 x 19 )
    20 x 35mm
    BMP-1235
    25 x 42mm
    BMP-1225
    BMP-1625
    30 x 52mm
    BMP-1230
    BMP-1630
    BMP-2030
    35 x 60mm
    BMP-1235
    BMP-1635
    BMP-2035
    38 x 66mm
    BMP-1238
    BMP-1638
    BMP-2038
    BMP-2438
    40 x 69mm
    BMP-1240
    BMP-1640
    BMP-2040
    BMP-2440
    BMP-3040
    50 x 86mm
    BMP-1250
    BMP-1650
    BMP-2050
    BMP-2450
    BMP-3050
    60 x 104mm
    BMP-1260
    BMP-1660
    BMP-2060
    BMP-2460
    BMP-3060
    70 x 120mm
    BMP-1270
    BMP-1670
    BMP-2070
    BMP-2470
    BMP-3070
    76 x 131mm
    BMP-1276
    BMP-1676
    BMP-2076
    BMP-2476
    BMP-3076
    80 x 138mm
    BMP-1280
    BMP-1680
    BMP-2080
    BMP-2480
    BMP-3080
    90 x 154mm
    BMP-1290
    BMP-1690
    BMP-2090
    BMP-2490
    BMP-3090
    100 x 173mm
    BMP-12100
    BMP-16100
    BMP-20100
    BMP-24100
    BMP-30100
    120 x 206mm
    BMP-12120
    BMP-16120
    BMP-20120
    BMP-24120
    BMP-30120
    Cable Mesh : Stainless steel 304,304L,316,306L etc.
    SS304
    (%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
    SS316
    (%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
    SS316L
    (%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0~18.0, Ni:12.0~15.0
    Architectural Cable Wire Mesh by Yuntong made from stainless steel wires, and has skin-like characteristics. It can form a plane surface but can also be tensioned into three-dimensional forms featuring funnel-like, cylindrical or spherical.
    Stainless Steel Cable Mesh is custom manufactured to in widths and lengths to suit your architectural application. Finished diamond mesh style when it is stretched at 60 degree angle ; Diagonal and irregular shapes can also be supplied. Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design and the required aesthetics.
    Facade Cladding Or Architectural Wire Mesh / Stainless Steel Cable Mesh 0
    Recommended Stainless Steel Cable Mesh Specification For Architectural Facade :
    Material
    Cable Diameter
    Hole Size
    Normal Break
    SS304/316/316L
    3/32" (2.4MM)
    2.5" x 2.5"
    920LBS
    SS304/316/316L
    3/32" (2.4MM)
    3" x 3"
    920LBS
    SS304/316/316L
    3/32" (2.4MM)
    4" x 4"
    920LBS
    SS304/316/316L
    5/64" (2.0MM)
    2.5" x 2.5"
    676 LBS
    SS304/316/316L
    5/64" (2.0MM)
    3" x 3"
    676 LBS
    SS304/316/316L
    5/64" (2.0MM)
    4" x 4"
    676 LBS
    X-TEND Stainless steel mesh is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of X-TEND – the mesh can even stand up to heavy loads.
    Facade Cladding Or Architectural Wire Mesh / Stainless Steel Cable Mesh 1
    Facade Cladding Or Architectural Wire Mesh / Stainless Steel Cable Mesh 2Facade Cladding Or Architectural Wire Mesh / Stainless Steel Cable Mesh 3
